| Model Number : | YW-16164G3 |
| Price : | $4 |
Parameters of YW-16164G3 Global Positioning System Module
Item | Parameters |
Part No. | YW-16164G3 |
Chipset | As per order |
Frequency | Optional |
Number of Channels | Optional |
Positioning Accuracy | Customized |
Velocity | 515 m/s |
Velocity Accuracy | Without aid : 0.1m/s DGPS: 0.05m/s |
TTFF | Hot start: 1 second typical Warm start: 28 seconds typical Cold start: 30 seconds typical |
Sensitivity | Tracking Sensitivity: -162 dBm Acquisition Sensitivity: -160 dBm typical Cold Start:-147dBm |
Baud Rate | 9600 bps (default) |
Max Navigation Update Rate | 1Hz (default), maximum 10Hz |
Timing Accuracy | 25 ns RMS |
Interface Options | UART, I2C, SPI, USB |
Data Output Format | NMEA 0183 |
Power Supply | 3.3V ~ 5V |
Power Consumption | 30mA acquisition, 24mA tracking |
Working Temperature Range | -40°C to 85°C |
Antenna Type | patch ceramic antenna |
AGPS | Supported |
Dimension | 16*16*4mm |
Package Type | SMD |
Pin Assignment of YW-16164G3 GPS Positioning Module
Pin No. | Pin name | I/O | Description | Remark |
1 | GND | O | power output ground | |
2 | VCC | I | Main power supply to the engine board | Voltage range: 3V~5V |
3 | TX | O | Data output | |
4 | VBAT | P | Ground |
|
|
